Expanding my virtual hard disk

Expanding my virtual hard disk

filelight utility running on UbuntuMost Linux development is done on Ubuntu running under Hyper-V on my Windows 10 PC. If you have lots of RAM (and I have a full 64 GB), it’s very convenient. I run Snagit on Windows and this makes it very easy to grab screenshots of the Ubuntu window.

I also have a “Raspberry-pi” running under Hyper-V.  There’s a Raspbian desktop that you can download and run in Hyper-V, VirtualBox or VMWare though I’ve only done Hyper-V. Don’t forget when you are running a Raspberry Pi this way that its x86 based not ARM. That does affect the available software, so it doesn’t behave exactly like a real Pi though often close enough.

Today though I started getting low disk space from my virtual Ubuntu. That’s the problem with virtual machines. When you first setup a Virtual hard disk, you never know just how much disk space you will need.

There’s a terminal command that shows how much space you have left.

df -h --total

This produced this

david@david-Virtual-Machine:~$ df -h --total
Filesystem      Size  Used Avail Use% Mounted on
udev            942M     0  942M   0% /dev
tmpfs           193M  1.4M  192M   1% /run
/dev/sda1        11G  9.9G  603M  95% /
tmpfs           964M     0  964M   0% /dev/shm
tmpfs           5.0M     0  5.0M   0% /run/lock
tmpfs           964M     0  964M   0% /sys/fs/cgroup
/dev/sda15      105M  3.6M  101M   4% /boot/efi
tmpfs           193M   16K  193M   1% /run/user/121
tmpfs           193M   24K  193M   1% /run/user/1000
total            14G  9.9G  4.1G  71% -

This was after I’d extended my virtual hard disk.  You can see I now have 4.1 GB free.

The pretty picture is from a utility filelight. You install it in the usual way

sudo apt install filelight

Or if you prefer a more visual insight, install qdirstat.

sudo apt install qdirstat

This is like WinDirStat on Windows but qdirstat seems to run many times faster. It took a couple of seconds to produce this image below. WinDirStat would take 10-30 minutes.

qdirstat















So how did I expand my Hyper-V hard drive?

First you have to get rid of any checkpoints. Save your Hyper-V session if open then delete the checkpoint.

Delete Hyper-V checkpointRight click on the checkpoint for the selected VM and click delete. This will take a minute or two and you’ll see it have a Merging status. You may need to shutdown the VM.

After that you can go into the settings and it will let you edit the virtual hard drive and change the size.

Code::Blocks revisited

Code::Blocks revisited

Code::Blocks SDL2 demoSo after yesterday’s post I also installed Code::Blocks on Ubuntu 20.04 LTS, the recent six monthly Ubuntu release. Guess what, it’s a much newer version of Code::Blocks that looks slightly different and does include SDL2. Although the demo program it creates is C++ not C (That coloured bar picture is the demo).  I haven’t used it enough to see what’s different between this and version 16.01.

The version of Code::Blocks on the 18.04LTS Ubuntu  was 16.01 and on Ubuntu 20.04 LTS it’s Code::Blocks 20.03. I keep my Ubuntus up to date but the 18.04 LTS hasn’t switched to the newer Code::Blocks which surprised me. I’m guessing that the maintainers of the 18.04 LTS Ubuntu repositories just haven’t updated their copy of Code::Blocks.

One thing I hadn’t explored in Code::Blocks is the debugging and this seems a lot more powerful than what you get in Visual Studio Code.   This screenshot below from version 20 shows it is more akin to Visual Studio debugging rather than Visual Studio Code debugging what with CPU registers, stack, memory dump and threads.

Code::Blocks Debugging Menu
